Product Summary

The 2920L075/60MR Polyfuse resettable PTC provides surface mount overcurrent protection for medium voltage (≤60V) applications where resettable protection is desired. Applications of the 2920L075/60MR include: IEE1394 port protection, Powered ethernet port protection (IEEE 802.3 af) , Automotive electronic control module protection and Low voltage telecomequipment protection.

Parametrics

2920L075/60MR absolute maximum ratings: (1) (1) Ihold: 0.75A; (2) Itrip: 1.5A; (3) Vmax: 30Vdc; (4) Pd max. (w) : 1.50W; (5) Current: 8.00A; (6) Time (sec.) : 0.30 sec. ; (7) Rmin (Ω) : 0.30Ω; (8) Rtyp (Ω) : 0.67Ω; (9) R1max( Ω) : 1.00Ω.

Features

2920L075/60MR features: (1) RoHS compliant and lead-free; (2) Fast response to fault currents; (3) High voltage; (4) Low-proile.

Diagrams

2920L075/60MR Dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
2920L075/60MR
2920L075/60MR
Littelfuse
PTC Resettable Fuses PTC PLYFUSE SMT 2920 60V .750A
Data Sheet
0-1: $0.23
1-10: $0.23
10-100: $0.22
100-250: $0.21
