Product Summary

The E2K-L26MC1 is an OMRON Liquid Level Sensor.

Parametrics

E2K-L26MC1 absolute maximum ratings: (1)Repetition precision: ±0.2 mm max.; (2)Supply voltage (operating voltage range): 12 to 24 VDC, 10% max. ripple (10.8 to 30 VDC); (3) Response difference: 0.3 to 3 mm; (4)Current consumption: 12 mA max.; (5) Control output : Switching capacity: 100 mA max., Residual voltage: 1 V max; (6)Storage temperature: -10℃ to +65℃; (7)Operating temperature: 0℃ to +55℃ with no icing; (8)Operating humidity: 25% to 85%; (9)Weight: Approx. 70 g.

Features

E2K-L26MC1 features: (1)Installation on pipes; (2)Sensing by means electrostatic capacity and is not influenced by the color of the pipe or liquid; (3)Available in 8 to 11 mm dia. and 12 to 26 mm dia. models to enable sensing for a wide range of pipe diameters; (4)Built-in amplifier for space-saving.

Diagrams

E2K-L26MC1 dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
E2K-L26MC1
E2K-L26MC1
Omron Industrial
Proximity Sensors CAP PROX NO NPN12-26 mmDia2mCbl
Data Sheet
0-1: $81.52
1-5: $76.15
5-10: $73.74
10-20: $72.40
