Product Summary

The G5LE-14-12V 24V is an OMRON PCB Relay. It is a A Cubic, Single-pole 10-A Power Relay.

Parametrics

G5LE-14-12V 24V absolute maximum ratings: (1)Rated voltage: 12VDC; (2)Rated current: 33.3 mA; (3)Coil resistance: 360Ω; (4)Must operate voltage: 75% max. of rated voltage; (5)Must release voltage: 10% min. of rated voltage; (6)Max. voltage: 130% of rated voltage at 85℃, 170% of rated voltage at 23℃; (7)Power consumption: Approx. 400 mW.

Features

G5LE-14-12V 24V features: (1)Subminiature "sugar cube" relay with universal terminal footprint; (2)Tracking resistance: CTI>250 (-VD type); (3)UL class-F coil insulation model available (UL class-B coil insulation for standard model); (4)High switching power: 10 A; (5)Two types of seal available; flux protection and fully sealed; (6)Withstands impulse of up to 4,500 ; (7)400-mW and 360-mW coil power consumption types available; (8)Pre-soldered terminals.

Diagrams

G5LE-14-12V 24V dimension figure
