Product Summary

The VI-2N3-05 is a DC-DC Converter. It is Vicor’s first generation of “zero-current-switching” component-level DC-DC converter. Operating at frequencies up to 2 MHz, it offer exceptional power density, efficiency, noise performance, reliability and ease of use. Power Boosters provide a simple, cost effective, off-the-shelf solution for higher power output requirements. One or more boosters may be used to create synchronous arrays capable of supplying several kilowatts of output power.

Parametrics

VI-2N3-05 absolute maximum ratings: (1)Input Voltage: Nominal: 48V, Range: 36 – 76V, Brownout/Transient: n/a n/a; (2)Output Voltage: 24V.

Features

VI-2N3-05 features: (1)Up to 50W/Cubic Inch; (2)UL, CSA, TUV, VDE, BABT; (3) Up to 90% Efficiency; (4)Size: 4.6" x 2.4" x 0.5" (116,8 x 61,0 x 12,7); (5)Remote Sense and Current Limit; (6)OVP, Thermal Shutdown; (7) Logic Disable; (8) Wide Range Output Adjust; (9) Compatible Power Booster Modules; (10) ZCS Power Architecture; (11) Low Noise FM Control; (12) CE Marked.

Diagrams

VI-2N3-05 dimension figure
