Product Summary

The ikw40n120t2 is an IGBT in 2nd generation TrenchStop with soft, fast recovery anti-parallel EmCon diode.

Parametrics

ikw40n120t2 absolute maximum ratings: (1) Collector-emitter voltage VCE: 1200V; (2) DC collector current (Tj=150°C), Tc=25°C: 75A, Tc=110°C: 40A; (3) Pulsed collector current, tp limited by Tjmax, Icpuls: 160A; (4) Turn off safe operating area VCE≤1200V, Tj≤175°C: 160A; (5) DC Diode forward current (Tj=150°C), Tc=25°C, IF: 75A, Tc=110°C: 40A; (6) Diode pulsed current, tp limited by Tjmax, IFpuls: 160A; (7) Gate-emitter voltage VGE: ±20V; (8) Power dissipation Tc=25°C, Ptot: 480W; (9) Operating junction temperature: -40 to +175°C; (10) Storage temperature Tstg: -55 to +150°C; (11) Soldering temperature, 1.6mm (0.063 in.) from case for 10s Wavesoldering only, temperature on leads only : 260°C.

Features

ikw40n120t2 features: (1) Best in class TO247; (2) Short circuit withstand time: 10μs; (3) TrenchStop 2nd generation for 1200 V applications; (4) Easy paralleling capability due to positive temperature coefficient in VCE (sat) ; (5) Low EMI; (6) Low Gate Charge; (7) Very soft, fast recovery anti-parallel EmCon HE diode; (8) Qualified according to JEDEC for target applications; (9) Pb-free lead plating; RoHS compliant; (10) Complete product spectrum and PSpice Models.

Diagrams

IKW40N120T2 Test Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
IKW40N120T2
IKW40N120T2
Infineon Technologies
IGBT Transistors LOW LOSS DuoPack 1200V 40A
Data Sheet
0-130: $4.91
130-250: $4.52
250-500: $4.12
500-1000: $3.59
