Product Summary
The FF300R06KE3 is a 62mm C-series module with fast trench/fieldstop IGBT4 and optimized EmCon diode. The applications of the FF200R12KT3 are High Power Conberters, moto driver and UPS systems.
Parametrics
FF300R06KE3 absolute maximum ratings: (1)Collector-emitter Voltage(Tvj=25℃): 600V ; (2)DC-collector current: Tc=80℃, Tvj=150℃, Ic nom=300A; Tc=25℃, Tvj=150℃, Ic nom=400A; (3)Repetitive Reak Current(tp=1ms): 600A; (4)Total Power Dissipation(Tc=25℃, Tvj=150℃): 940W ; (5)Gate-emitter Peak Voltage: +/-20V.
Features
FF300R06KE3 features: (1)Collector-emitter saturation voltage(IC=300A, VGE=15V, Tvj=25℃): 1.45-1.90V; (2)Gate threshold voltage(IC=4.80mA, VCE=VGE, Tvj=25℃): 4.9-6.5V; (3)Gate charge(VGE=-15V...+15V): 3.20μC; (4)Internal gate resistor(Tvj=25℃): 1.0Ω; (5)Input capacitance(f=1MHz, Tvj=25°C, VCE=25V, VGE=0V): 19.0nF; (6)Collector-emitter cut-off current(VCE=600 V, VGE=0V, Tvj=25°C): 5.0 mA.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 FF300R06KE3 |
Infineon Technologies |
IGBT Modules N-CH 600V 400A |
Data Sheet |
|
|
||||||||
|
FF300R06KE3_B2 |
Infineon Technologies |
IGBT Modules IGBT 600V 300A |
Data Sheet |
|
|
||||||||
