Product Summary
The cm50md1-12h is a medium power switching use insulated type Mitsubishi IGBT module. Applications of the cm50md1-12h include: AC & DC motor controls, General purpose inverters, Servo controls, NC, Robotics.
Parametrics
cm50md1-12h absolute maximum ratings: (1) Collector-emitter voltage VCES: 600V (G-E short) ; (2) Gate-emitter voltage VGES: ±20V (C-E short) ; (3) Collector Current IC: 30A (Tc=25°C) , ICM: 60A (PULSE) ; (4) Emitter Current IE: 30A (Tc=25°C) , IEM: 60A (PULSE) ; (5) Maximum collector dissipation Pc: 66W (Tf=25°C) .
Features
cm50md1-12h features: (1) IC: 30A; (2) VCES: 600V; (3) Insulated type; (4) CIB module; (5) UL recognized.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 CM50MD1-12H |
Other |
|
Data Sheet |
Negotiable |
|
||||
