Product Summary

The cj2m-cpu11 is a sysmac Cj-series CJ2M CPU unit. The cj2m-cpu11 is control of a wide variety of applications worldwide. The accumulated experience and advancements in technology now result in the cj2m-cpu11; fully compatible, yet fully new.

Features

cj2m-cpu11 features: (1) Five variations in program capacity from 5K steps to 60K steps; scale the CPU to your application needs; (2) Faster processors; LD instruction execution time is reduced to 40 ns, floating point trigonometrics in less than 1μs; (3) Faster Function Block calls and execution, faster interrupt handling, less overhead time; (4) Added execution memory for Function Blocks allows structured, object-oriented programming even in entry-level CPUs; (5) General-purpose Ethernet port supports EtherNet/IP tag-based data links, connection to Support Software, communications between PLCs, FTP data transfers, and more; (6) Standard USB port on all models allows Support Software to connect directly through standard USB cable; (7) A Serial Option Module can be mounted to add RS-232C or RS-422A/485 communications ports; (8) Compatible with all existing CJ1 power supply-, I/O-, control- and communication units.

Diagrams

cj2m-cpu11 dimension

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CJ2M-CPU11
CJ2M-CPU11

CJ2M CPU RS232 5K STEPS
Data Sheet
0-1: $336.60
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CJ2M-CPU11
CJ2M-CPU11

CJ2M CPU RS232 5K STEPS
Data Sheet
0-1: $336.60
CJ2M-CPU12
CJ2M-CPU12

CJ2M CPU RS232 10K STEPS
Data Sheet
0-1: $415.80
CJ2M-CPU13
CJ2M-CPU13

CJ2M CPU RS232 20K STEPS
Data Sheet
0-1: $550.44
CJ2M-CPU14
CJ2M-CPU14

CJ2M CPU RS232 30K STEPS
Data Sheet
0-1: $708.84
CJ2M-CPU15
CJ2M-CPU15

CJ2M CPU RS232 60K STEPS
Data Sheet
0-1: $867.24
CJ2M-CPU31
CJ2M-CPU31

PLC CONTROLLER 40I/O
Data Sheet
0-1: $608.15
1-25: $587.88
25-50: $567.61
50-100: $547.34
100-250: $527.07
250-500: $516.93
500-1000: $506.79
