Product Summary
The US1M is a surface mount ultra fastswitching rectifier.
Parametrics
US1M absolute maximum ratings: (1) Maximum Repetitive Peak Reverse Voltage VRRM: 1000V; (2) Maximum RMS Voltage VRMS: 700V; (3) Maximum DC Blocking Voltage VDC: 1000V; (4) Maximum Average Forward Rectified Current (TL=100°C) IF (AV) : 1.0A; (5) Peak Forward Surge Current (8.3ms single half sine-wave superimposed on rated load) IFSM: 30A; (6) Maximum Instantaneous Forward Voltage (at rated forward current) VF: 1.7V; (7) Maximum DC Reverse Current (at rated DC blocking voltage) Ta=25°C, IR: 5.0μA, 200μA (ta=100°C) ; (8) Maximum Reverse Recovery Time trr: 75nS; (9) Typical Junction Capacitance Cj: 10pF; (10) Typical Thermal Resistance Rθ (ja) : 32°C/W; (11) Storage and Operation Junction Temperature: -55 to +150°C.
Features
US1M features: (1) Ideal for surface mount pick and place application; (2) Low profile package; (3) Built-in strain relief; (4) High surge capability; (5) Glass passivated chip; (6) Ultra fast recovery for high efficiency; (7) High temperature soldering guaranteed: 260°C /10sec/at terminal.
Diagrams
Image | Part No | Mfg | Description | ![]() |
Pricing (USD) |
Quantity | ||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
![]() US1M |
![]() Taiwan Semiconductor |
![]() TVS Diodes - Transient Voltage Suppressors 1500W 20V 5% UNI TRANSZORB-TVS |
![]() Data Sheet |
![]()
|
|
||||||
![]() |
![]() US1M/1 |
![]() |
![]() DIODE FAST 1A 1000V SMA |
![]() Data Sheet |
![]()
|
|
||||||
![]() |
![]() US1M/11T |
![]() Vishay Semiconductors |
![]() Rectifiers 1 AMP 1000 VOLT |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() US1M/13T |
![]() Vishay Semiconductors |
![]() Rectifiers 1000 Volt 1.0A 75ns 30 Amp IFSM |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() US1M/1T |
![]() Vishay Semiconductors |
![]() Rectifiers 1000 Volt 1.0A 75ns 30 Amp IFSM |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() US1M/2FT |
![]() Vishay Semiconductors |
![]() Rectifiers 1000 Volt 1.0A 75ns 30 Amp IFSM |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() US1M/2GT |
![]() Vishay Semiconductors |
![]() Rectifiers 1000 Volt 1.0A 75ns 30 Amp IFSM |
![]() Data Sheet |
![]() Negotiable |
|
||||||
![]() |
![]() US1M/51T |
![]() Vishay Semiconductors |
![]() Rectifiers 1000 Volt 1.0A 75ns 30 Amp IFSM |
![]() Data Sheet |
![]() Negotiable |
|
