Product Summary

AO3401A is a P-channel enhancement mode field effecttransistor. The AO3401A uses advanced trench technology to provide excellent RDS(ON) , low gate charge and operation gate voltages as low as 2.5V. The is suitable for use as a load switch or other general applications.AO3401A is Pb-free (meets ROHS & Sony 259 specifications) .

Parametrics

AO3401A absolute maximum ratings: (1) Drain-Source Voltage VDS: -30V; (2) Gate-Source Voltage VGS: ±12V; (3) Continuous Drain ID: -4.3A (TA=25°C) , Current A,F IDM: -3.8A (TA=70°C) ; (4) Pulsed Drain Current IDM: -25A; (5) Power Dissipation PD: 1.4W (TA=25°C) , 0.9W (TA=70°C) ; (6) Junction and Storage Temperature Range Tj, TSTG: -55 to 150°C.

Features

AO3401A features: (1) VDS (V) =-30V; (2) ID=-4.3A; (3) RDS (ON) < 46mΩ (VGS=-10V) ; (4) RDS (ON) < 55mΩ (VGS=-4.5V) ; (5) RDS (ON) < 80mW (VGS=--2.5V) .

Diagrams

AO3401A Circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AO3401A
AO3401A

MOSFET P-CH -30V -4.3A SOT23
Data Sheet
0-1: $0.27
1-25: $0.18
25-100: $0.15
100-250: $0.12
250-500: $0.10
500-1000: $0.07
