Product Summary

EFB0405HHA is a DC FAN.

Parametrics

EFB0405HHA absolute maximum ratings: (1)Rated Voltage: 5VDC; (2)Operating Voltage Range: 4.5V to 5.5V; (3)Rated Current: 0.19A; (4)Rated Input Power: 0.95W; (5)Speed: 7000 R.P.M; (6)Maximum Air Flow: 0.229 m3/min, 8.09 CFM; (7)Maximum Air Pressure: 4.42 mmH2O, 0.174 INH2O; (8)Noise: 33.0dB-A.

Features

EFB0405HHA features: (1)Bearing Type: Ball Bearings; (2)Material: Impeller & Frame: Plastic(UL 94V-0); (3)Lead Wires: UL 1007 AWG #28 OR Equivalent, Red Wire Positive(+), Black Wire Negative(-); (4)Weight: 14.5g (0.51 OZ); (5)Rib Type Only.

Diagrams

EFB0405HHA dimension figure

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
EFB0405HHA-F00
EFB0405HHA-F00

5V DC FAN 40X40X10 MM
Data Sheet
0-1: $6.35
1-10: $5.81
10-25: $4.86
25-50: $4.46
50-100: $3.92
100-250: $3.65
250-500: $3.38
500-1000: $3.24
Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
EFB0405HD
EFB0405HD

FAN DC AXIAL 5V 40X20 7600RPM
Data Sheet
0-1: $6.70
1-10: $6.13
10-25: $5.13
25-50: $4.70
50-100: $4.13
100-250: $3.85
250-500: $3.56
500-1000: $3.42
EFB0405HD-F00
EFB0405HD-F00

5V DC FAN 40X40X20 MM
Data Sheet
0-1: $7.05
1-10: $6.45
10-25: $5.40
25-50: $4.95
50-100: $4.35
100-250: $4.05
250-500: $3.75
500-1000: $3.60
EFB0405HHA-F00
EFB0405HHA-F00

5V DC FAN 40X40X10 MM
Data Sheet
0-1: $6.35
1-10: $5.81
10-25: $4.86
25-50: $4.46
50-100: $3.92
100-250: $3.65
250-500: $3.38
500-1000: $3.24
EFB0405HHD
EFB0405HHD

5V DC FAN 40X40X20 MM
Data Sheet
0-1: $6.70
1-10: $6.13
10-25: $5.13
25-50: $4.70
50-100: $4.13
100-250: $3.85
250-500: $3.56
500-1000: $3.42
EFB0405LA
EFB0405LA

5V DC FAN 40X40X10 MM
Data Sheet
0-1: $5.99
1-10: $5.48
10-25: $4.59
25-50: $4.21
50-100: $3.70
100-250: $3.44
250-500: $3.19
500-1000: $3.06
EFB0412HA
EFB0412HA

FAN DC AXIAL 12V 40X10 6000RPM
Data Sheet
0-1: $5.99
1-10: $5.48
10-25: $4.59
25-50: $4.21
50-100: $3.70
100-250: $3.44
250-500: $3.19
500-1000: $3.06
